Drilling machines & boring mills

2 Bohreinheiten mit Steuerung

Arbeitszyklus wird beim schliesen der Abdeckung ausgelöst

Pneumatischer Vorschub

Pneumatische Werkstückspannung

Sehr guter Zustand

Verschiedene Bohröpfe Mehrspindelbohrköpfe stehen zur Verfügung

Suhner Bohrmaster Siegloch und Schrieder

Preis ohne Köpfe netto + Steuer 19% = 3094.-€

Preis inkl Steuer 19%

Sie erhalten eine Rechnung

Hub 100 mm

komplett mit Aufspanntisch (30 mm Stahlplatte)

und Kühlmittelpumpeund Werkstückspanner

Preis netto 2184,87 + steuer 19% = 2600.- inkl Steuer brutto

mit 6 Bohrköpfen Nottmeyer 64x64 mm Bohrerabstand

mit 6 Pneumatischen Anschlägen

mit manuellen Anschlägen

20 Progammen

Absaughaube

Lieferung in der Umgebung möglich

Preis 2800 Netto + steuer 19% = 3332.-€ brutto inkl steuer

Mit Untergestell und Schnellspannfutter max ca 200mm über Bett

Ausladung ca 110 mm

für leichte Bohrarbeiten bei denen das Werkstück mit beiden Händen festgehalten werden kann

Preis 400 + Steuer 19% = 476.-€ brutto

Lieferung nur in der Umgebung von Presseck oder Fürth möglich

Preis netto 300 + steuer = 357 .- € Brutto

Bohrhub ca 6 cm Ausladung Ca 20 cm

Auslöung Bohrhub über Tastbrett durch

Oberschenkel

tiefe den Anschlags

pneumatisch verstellbar

Sicherheitsabschaltung Ausziehbahre Auflage

bis 400 cm Absaugung mit Pneumatikschieber

preis 1600 ikl Steur 19%

1 Stüch Bohvorichtung mit 3 Bohreineiten Sugino ESB 1306

Preis 2000 .- € ink Steuer

1 Stüch Bohvorichtung mit 2 Bohreineiten Sugino ESB 1309

Preis 1500 .- € ink Steuer

1 Stüch Bohvorichtung mit 2 Bohreineiten Sugino ESB 1310

mit Kühlmittelpumpe

Preis 1500 .- € ink Steuer mit

in einer anderen Anzeige biete ich Sugino Tapper Gewindeschneideinheiten an

3 Stueck STB - L 108 mit 3 Stueck Controller

UC 21 U mit Twin Tap Head 2-TC E 30- 80AF,

Chuking ´M 3 ~ M8 Pitch 23- 91 mm

Bohrerabstand 23 bis 91 mm verstelbar Hub

max 80mm 1 Stueck STC - P 316 mit 1 Stueck

Controller UC 22 U mit 2 Stueck Multi Tap

Head 18,75 mm und 32 mm Bohrerabstand 75

mm Stange Hub 120 mm Mit 1 Stueck

Grundplatte fuer Stb108 und 1 Stueck

Grundplatte fuer STC 316 mit pneumaticher

Spannvorrichtung

Preis Netto 4100+ Steuer 19%

Preis inkl Steuer 19% 4879.-€

Sie erhalten eine Rechnung

Bohrgruppe mit 2 Bohraggregaten Grotefeld,

gekröpft mind. Abstand 32 mm; Abstand kannleicht verändert werden

2x 0,45 KW /

2750 u/min hub ca 45 mm Bohreraufname

Spannschraube oder Innengewinde M 10

Mehrfachanschlag mit Spannzylinder und

Abblaseinrichtung

Preis netto1218,85 + steuer = 1450.-€ brutto

Net weight: 700 kg

Overall dimensions: 1.15 m × 1.1 m × 2.1 m

Condition: Used

Stable double-column drilling machine with

- 2 motor stages

- Height-adjustable worktable

- 2 x 0.9 kW drive

- 2 x MK 1 spindle holder

The outreach of 330 mm and drilling stroke of 120 mm with a maximum workpiece height of 750 mm places it in the upper machining range.

Drilling capacity (diameter): 23 mm

Clamping area: 760 × 360 mm

The machine is in very good condition.

Machine type: Column drilling machine

Control type: Conventional

Location: Eislingen

Country of origin: Germany

Delivery time: By arrangement

Shipping terms: Ex Warehouse

Drilling speed: 180 - 1600 rpm

Maximum workpiece height: 750 mm

Total power requirement: 2 x 0.9 kW

Spindle holder: 2 x MK 1

Column diameter: 2 x 130 mm

Year of manufacture: 1966

Net weight: 1,300 kg

Overall dimensions: 1.2 m × 1.2 m × 2.3 m

Condition: Used

Rapid radial drilling machine with automatic feed, thread cutting device,

hydraulic quick clamping, motorized height adjustment with rapid traverse,

cooling system, machine base suitable for mounting a second drilling table,

safety emergency stop.

Machine type: Rapid radial drilling machine

Control type: Conventional

Location: Eislingen

Country of origin: Germany

Delivery time: By arrangement

Shipping terms: Ex Warehouse

Drive power: 2.2 kW

Clamping table: 1300 × 550 mm

Outreach: 1000 mm

Drilling capacity in steel (diameter): 32 mm

Drill spindle Morse taper: MK4

Speed range (stepless): 80 - 1500 rpm

Feed: 8 steps 0.003 - 0.25 mm/min

Maximum workpiece height: 650 mm

Column diameter: 210 mm

Cooling system

Net weight: 3,400 kg

Overall dimensions: 1 m × 2.5 m × 2.8 m

Condition: Used

Radial drilling machine in compact design with hydraulic quick clamping,

electric height adjustment, feed device, thread cutting device,

clamping slots in the machine bed, cube table.

Very high rigidity and extremely robust.

Machine is in excellent used condition.

Machine type: Radial drilling machine

Control type: Conventional

Location: Eislingen

Country of origin: Italy

Delivery time: Immediate

Shipping terms: From location

Drilling capacity in steel (diameter): 55 mm

Outreach: 1600 mm

Maximum workpiece height: 1400 mm

Drilling capacity in cast iron: 65 mm

Quill diameter: 80 mm

Quill stroke: 340 mm

Drill spindle Morse taper: 5

Drilling speed range: 25 - 2000 rpm

Column diameter: 350 mm

Stepless feed: 0.032 to 1.6

Cube table: 625 × 500 × 495 mm

Table size (machine base): 1700 × 1000 mm

Main drive motor power: approx. 5.0 kW

Total power requirement: approx. 7.5 kW

Cooling system

Hydraulic clamping

Electric height adjustment

Thread cutting device

Net weight: 76 kg

Overall dimensions: 0.28 m × 0.6 m × 0.7 m

Condition: Used

Machine type: Thread drilling machine

Control type: Conventional

Location: Eislingen

Country of origin: Germany

Delivery time: By arrangement

Shipping terms: Ex Warehouse

Thread diameter: 12 mm

Thread length: 40 mm

Outreach: 160 mm

Maximum workpiece dimensions: 200 mm

Speed: 450 - 2200 rpm

Total power requirement: 0.37 / 0.3 kW

Year of manufacture: 2001

Net weight: 640 kg

Overall dimensions: 1.05 m × 0.75 m × 1.95 m

Condition: Used

Precision column drilling machine with 60 mm drilling capacity in steel,

stepless spindle speed (65 - 1800 rpm), switchable feed gearbox,

2-pole reversible drive motor, forward/reverse,

adjustable drilling feed (0.075 - 0.25 mm/rev), height-adjustable,

swiveling and rotating worktable, machined base (410 × 370 mm),

main machine switch, safety emergency stop switch, analog speed display,

machine lighting, machine is in good condition

Machine type: Anvil

Control type: Conventional

Location: Eislingen main warehouse

Country of origin: Germany

Delivery time: Immediate

Drilling capacity in steel (diameter): 60 mm

Outreach: 300 mm

Drilling stroke: 160 mm

Speed: 65 - 1800 rpm (stepless)

Table surface area: 475 × 455 mm

Feed rates: 0.075 / 0.1 / 0.2 / 0.25 mm/rev

Table height adjustable to: 850 mm

Table swivel: 180 degrees

Column diameter: 140 mm

Spindle holder: MK 4

Cooling system

Machined base plate

Net weight: 800 kg

Overall dimensions: 1.1 m × 0.7 m × 2.9 m

Condition: Used

Very stable and powerful precision column drilling machine with switchable feed gearbox,

forward/reverse operation, adjustable drilling feed (0.12 - 0.4 mm/rev),

height-adjustable, swiveling and rotating round table (Ø 630 mm), machined base (440 × 460 mm),

cooling system, safety main switch.

The machine is in good condition.

Machine type: Anvil

Control type: Conventional

Location: Eislingen main warehouse

Country of origin: Germany

Delivery time: Immediate

Shipping terms: Ex Warehouse

Drilling capacity in steel (diameter): 40 mm

Outreach: 390 mm

Drilling stroke: 150 mm

Table surface: Ø 630 mm

Speed range: 26 steps

Feed range: 0.12 - 0.4 mm/min (4 steps)

Column diameter: 250 mm

Distance spindle/table: 0 - 825 mm

Distance spindle/base plate: 825 - 1200 mm

Drill head vertical adjustment: 380 mm

Table height adjustable: 490 mm

Spindle holder: MK 4

Net weight: 500 kg

Overall dimensions: 0.6 m × 1.4 m × 2.05 m

Condition: Used

Compact and very robust column drilling machine with height-adjustable and swiveling worktable,

with a clamping surface of 500 × 500 mm.

Feed rate of 0.1 - 0.3 m/min with a drilling stroke of 220 mm and an outreach of 280 mm.

Drilling capacity: 23 mm.

Machine is in good condition for its age.

Machine type: Anvil

Control type: Conventional

Location: Eislingen

Country of origin: Germany

Delivery time: By arrangement

Shipping terms: Ex Warehouse

Drilling capacity in steel (diameter): 23 mm

Outreach: 280 mm

Drilling stroke: 220 mm

Speed: 1420 rpm

Feed rate: 0.1 - 0.3 m/min

Maximum workpiece height: 950 mm

Clamping surface: 500 × 500 mm

Column diameter: 140 mm

Table swivel approx.: 180°

Machined base plate
