FP8102XR-G1 linear lithium-ion battery charger IC Feeling Technology

AB-2608-23
Hong Kong
Contact Person for this Ads:
Jason Mo
Languages
$ 1.90
$ 1.86
Key Features:
ManufactureFeeling Technology
ModelFP8102XR-G1
Quantity6300
Reference numberchipkindFP8102XR-G1
Condition
New
Ad Statistics:
Created8/18/2026
Last updated8/18/2026
Detailed view78
Contact Person for this Ads:
Jason Mo
Languages

Hong Kong

UNIT 60 3/F YAU LEE CENTER, NO.45 HOI YUEN ROAD KWUN TONG, KL

User Information
Registered Since8/18/2026
Number of Online Ads3
Last Sign in8/27/2026

FP8102XR-G1 is a standalone 1A linear lithium-ion battery charger IC developed by Feeling Technology Corp. It is designed for single-cell Li-ion battery charging applications and integrates constant-current/constant-voltage (CC/CV) charging control, charge termination, automatic recharge, thermal regulation, and battery status indication functions. With a compact SOP-8 exposed pad package and requiring only a few external components, the FP8102XR-G1 provides a simple and cost-effective charging solution for portable electronic devices.

Key Features

  • Standalone single-cell Li-ion battery charger
  • Programmable charging current up to 1A
  • Constant-current / constant-voltage (CC/CV) charging algorithm
  • Preset charge voltage:
  • 4.2V ±1%
  • No external MOSFET, current-sense resistor, or blocking diode required
  • Automatic recharge function
  • Charge termination based on C/10 current threshold
  • Trickle charging at low battery voltage:
  • Approx. 2.9V
  • Integrated thermal regulation and protection
  • Undervoltage lockout (UVLO)
  • Soft-start function to reduce inrush current
  • Charge status indicators:
  • Charging status
  • Standby / charge completion
  • Low standby current:
  • Approx. 55µA
  • Available in SOP-8L (Exposed Pad) package


Applications

  • Portable electronic devices
  • Handheld instruments
  • Mobile accessories
  • Charging docks and cradles
  • Battery-powered consumer electronics
  • Portable medical equipment
  • Small IoT devices
  • Single-cell lithium battery applications
